Purair FUMEBOX
- Low-profile, completely portable, no ductwork required.
- Compact size, easily positioned on shallow countertops or counters with overhanging wall cabinets.
- Clear viewing enclosure prevents chemical splash.
- Modular design permits multiple configurations.
Description
Model Specifications
Internal Height: 20.63″ | 524 mm
External Width: 20.72″ | 526 mm
External Depth: 12.02″ | 305 mm
External Height: 21.16″ | 537 mm
Shipping Width: 27″ | 686 mm
Shipping Depth: 27″ | 686 mm
Net Weight: 45 lbs | 20 kg
Shipping Weight: 60 lbs | 27 kg
Construction: Epoxy-coated Steel
OSHA: OSHA Standard -29 CFR, Safety and Health Regulations for General Industry, 1910.1450: Occupational exposure to hazardous chemicals in laboratories. Part B, definition, laboratory type hood. Please consult your Safety Officer and/or Industrial Hygienist.
Environmental: ISO 14001 : 2015; ENERGY STAR® Partner
Quality: ISO 9001 : 2015
Fume Extraction Unit - Source Capture Hose*: AP60EX
Spill Tray: TRAY-AP60
* Factory installed; specify when ordering
Airflow Direction: Crossflow
Electrical Voltage: 120V, 60Hz
NEMA Plug: 5-15P
Control: Electronic
Technical Info
| Model | Width | Depth | Height |
|---|---|---|---|
| AP60H-A | 20.72" | 526 mm | 12.02" | 305 mm | 21.16" | 537 mm |
| AP60V-A | 21.16" | 537 mm | 12.02" | 305 mm | 20.72" | 526 mm |
| AP60H-XL-A | 29.75" | 756 mm | 24.72" | 628 mm | 15.67" | 398 mm |
| Model | Width | Depth | Height |
|---|---|---|---|
| AP60H-A | 11" | 279 mm | 11.69" | 297 mm | 20.63" | 524 mm |
| AP60V-A | 20.63" | 524 mm | 11.69" | 297 mm | 11" | 279 mm |
| AP60H-XL-A | 29.22" | 742 mm | 13.82" | 376 mm | 15.32" | 389 mm |
| Formula | Description |
|---|---|
| GP Plus! | The most widely used filter in the range, primarily for solvent, organic and alcohol removal. |
| ACI Plus!/SUL | Designed to neutralize volatile inorganic acid vapors. |
| ACR | Iodine and methyl iodide vapors; It is frequently used for iodination reactions with lower level radioactive iodine. |
| ACM | Mercury vapor |
| AMM | Removes vapors from dilute ammonia solutions and to remove low molecular weight amines. |
| FOR | Designed to oxidize formaldehyde and glutaraldehyde fumes; It is widely used in hospital pathology laboratories. |
| HEPA/ULPA | Powders and particulates. |
Soldering \ Histology \ Cover Slipping \ Staining \ Pathology \ Graphic Arts, Sign Shops \ Art Conservation \ Electronics Assembly \ Particulate Control \ Manufacturing Processes \ Air Purification
